Power Supply |
380V 50Hz , 3 phase |
Power Input |
15KW |
Vacuum speed |
-760mmHg,15L/sec |
Max temp |
1450℃ |
Melting speed |
3-5min |
Max pressure |
2500hps |
Capacity |
2.4KG.(18k gold) |
Suitable Metal |
K Gold,Gold, silver, copper |
Casting item size |
127MM*235MM |
Cooling water |
water chiller or tap water (optional) |
Outside size |
W800xD900H1300mm |
Weight |
155KG |
Description
1. PID temp control system, max temp 1450℃, temp tolerance ±2℃. |
2. Strong electromagnetic stirring to ensure metal with even color. |
3. Automatic control and induction heating, high intelligent, fully auto or semi auto is for option, Chinese and English are swiched. |
4. More than 50 memory programs, any time you can check and change parameter setting, improve your casting quality, various casting mode for option. |
5. Whole casting process can visually seen, air pressing lock system, equipped with safety valve to ensure safety. |
6. Both melting and casting are done under vacuum condition, maximally control oxidation. |
7. Casting cylinder go up and down automatically helps casted items to be took out easily. |
8. Various size casting cylinder is for option. |
9. Big capacity, can cast 2.4kg 18k gold. |
10.Various alarm system, unit stops working immediately if any error occurred,maximally protect machine. |
11.Compact design , small size. |
12.Beading machine is for option. |
13.Unique casting cylinder separated from vacuum device, to reduce bubble to minimum. |
14.Touch interface, chinese and english adjustable, perfect combination of traditional workmanship and advanced technology. |
